1. Connect iKeycutter CONDOR XC-MINI Master to the PC with a USB cable.

2. Turn on the iKeycutter CONDOR XC-MINI Master.

3. Click "Update online" button to start update.

4. The screen will appear "Updating" prompt.

5. Wait for the update completed.

1: Do NOT turn off PC or unplug USB cable duing updating.

2: Data downloading and firmware upgrading may take a while, please be patient.

3: If the update fails, turn off anti-virus software and then try again.

How to Update Condor XC-Mini to V4.0.2 by Xhorse update kit

How to Operate iKeycutter Condor XC-Mini?

Note:Check the usermanual to get detail operating instruction with pictures.
How to use “Key Database”
User need to supply the key code, then can cutting the key.
1) Enter the Main interface, Click on Key Database
2) Choose the Car Brand, Click on Confirm
3) ①Enter the key code ②Click on Confirm
4) Enter the key serial code Click on Confirm
5) The Bitting Code will be found in the database, and it will be shown on the screen,Click on Cut to start.

How to use “Key Duplication”?

User need to supply the Car type and Year of the production
1) Enter the Main interface, Click on Key Duplication
2) ①Choose the Car Maker ②Click on Confirm
3) Choose Car Type, Click on Confirm
4) Choose the Car type and Year of the production, Click on Confirm.
5) Put the original Key in the properly position of the clamp display on the screen, then Click on Decode Key.
6) Verify bit code and modify bit code if needed, Click on Cut to start

How to use “Cut by Bitting”?

There are 2 methods to get the key using Cut by Bitting
Method 1: without the origin key using Cut by Bitting
1) Enter the Main interface, Click on Cut by Bitting
2) Choose the Blank Key, Click on Confirm
3) ①Select Key Type ②Click on Confirm
4) ①Put the Blank Key in the properly position of the clamp display on the screen ②Enter bitting and verify, then click on Cut to start

Method 2: existing the origin key using Cut by Bitting
1) Choose the Blank Key, Click on Confirm
2) Select Key Type, Click on Confirm
3) Click on Decode Key, the found bitting will display on the screen
4) Verify bitting and modify bitting if needed, Click on Cut to start。

How to use “Find Bitting”?

Parts of the car are missing bitting on door lock/trunk lock/ignition lock, enter unknown bitting as "?"
1) Enter the Main interface, Click on Find Bitting
2) ①Select Car Maker ②Click on Confirm
3) ①Select the Blank Key ②Click on Confirm
4) ①Select Key Type ②Click on Confirm
5) ①Enter known bitting ②Enter unknown bitting as "?" ③Click on Find Bitting Code

6) Possible key bitting will be listed. Note that system has sorted the codes by the most economical way in order to save blank keys. For example, the bitting under " First key" only needs three blank keys, the bitting under "Second Key" need another three blank keys, then the "third Key"...

1. Cut New GM, Coverlet, HU100, PSA Peugeot, Citroen VAT2 key, XC-MINI makes job easier
2.Do Toyota TOY43 all key lost, save you a lot of time
3.Cut Suzuki, Mazda (key tooth in ignition lock more than door lock) all key lost, simply by enter the key code
4.Do Hyundai, Kia, Peugeot, and Citroen all key lost, directly program keys
5. HU101 works fine, HU92 works fine.
6.HU66 OK, have to do two passes on each side to get the key to work, same with hu100.
7. Fix the problem that other Key Cutting Machines cut domestic Honda key not accurately
8.Clio 2 series with m1 clamp all is ok perfect
9. Panda MJ year 2005 cut key ok
10. Support “Define key tool” in a short time, for example: define 2015 corolla key
